OR-6090

Applications: Pencil sets, industrial and packaging applications, signs, display props, personality photos, photo frame production, crystal image products, handmade gifts, souvenirs, lighters, coasters, mobile phone case personalized products,U disk, keychain, ashtray, brooch, lunch box, belt, wallet, money clip, insole, personalized sports shoes, etc.

Personalized customized crystal label small flatbed printer
OR-6090 UV
Special for UV DTF Flatbed Printing, Most advanced and latest printing technology

Parameter

Print Head: Three i3200-U1 Print Heads
Max Print Size: 600mm
Colors : CMYK / W+CMYK / CMYK+V / W+CMYK+V

Feature

UV DTF Printing - The biggest advantage of this new technology is that after printing, it can be directly attached to the substrate to be transferred without other processing. UV DTF printing is especially suitable for transferring UV ink to special shapes and materials that are not suitable for direct printing by UV ink.
Download
New Feature of UV DTF Flatbed Printer
We have an excellent technical team, which can be designed according to customers requirements.
  • 01
    4 Colors + White & Varnish Are More Expressive
    Equipped with 6 ink tanks, 4 colors of ink can be installed. It can finish exquisite shading with high precision. In addition, using white ink and clear varnish, it has rich expressive power and fulfills various needs.
  • 02

    Print Varnish And 3D Relief Effects

    ​​​​​​​
    The heads of white color varnish ink jet at the same time, which can produce D relief and multi-layer transparent bump effect, including amazing varnish glossy effect and matte finish.
  • 03
    High-Performance Inks For A Variety Of Applications
    It is an eco-friendly UV ink with excellent color development and color reproducibility. It is cured by ultraviolet radiation. In addition to bright colors and style, it also has strong adhesion.
SPECIAL UV DTF PRINTING SOLUTION
UV DTF PRINTER With the rapid development of science and technology, people have shown unprecedented progress in the processing and presentation of image patterns.In order to meet the personalized demands of users and meet the needs of designers, UV flatbed printer has emerged as the times require, and its patterns are realistic and layered. The advantages of richness, high artistry, and strong stereoscopic effect make UV flatbed printer the first choice for hot image output.

UV DTF PRINTING SOLUTION
UV DTF printing is especially suitable for transferring UV ink to special shapes and materials that are not suitable for direct printing by UV ink.UV DTF Make you more easy to entry label market
- UV Direct Print Effect
- No Heating Process Required
- No Drying Process Required
- Good Adhesion on Curved, or Rugged Surface

UV DTF supports wide range of printing supplies
Direct to film comprehensive solution is a new technology of the digital revolution, The biggest advantage of this new technology is that after printing, it can be directly attached to the substrate to be transferred without other processing.


UV DTF INKS

All our UV DTF inks are specially developed and test to ensure
vivid colors and maximum fastness
- Scratch resistant
- Vivid colors


Epson i3200-U1 Print Head


PrecisionCore Technology a. MEMS manufacturing and thin film piezo element can
realize high precision and high density (600 npi/2 rows of nozzles). Contributes to
compact, high speed, high quality, and high image quality. b. Precision made of Epson
unique MEMS nozzles and an ink flow path ensure the perfectly round ink droplets are
placed accurately and consistently.

Epson i3200-U1 UV is a cost-effective 1.33inch-wide MEMs head series providing high productivity and high image quality with 600dpi high-density resolution. This printhead
is suitable for UV inks. It is unlocked.

 /Model I3200-U1 optional
Compatible ink UV Ink
Dimensions(WidthxDepthx Height) 69.1mm x 59.4mm x 35.6mm
Weight(g) 82
Nozzle Numbers 3200
Length Between Nozzles(inch) 1/300
Nozzle Row 4 rows
Max color/head 4 colors
Resolution 300dpi/row, 600dpi/2row
Effective Printing Width(mm) 33.8
Droplet
ejection
performance(kHz)
Binary 5 pl(43.2kHz)
3 levels
grey scale
6,12.5 pl(21.6kHz)
4 levels
 grey scale
3.8,6.2,9.3 pl(21.6kHz)
Viscosity range(mPa.s) 5-7 mPa・s

OR-6090 UV Printer
Printing Technology   i3200-U1 Print Heads
Print Head   Piezoelectric Inkjet
Printing Width   600*900(mm)
Acceptable Media Width ≤600(mm)
Thickness ≤150(mm)
Ink Cartridges Capacity Color Siphon + Regular Mixing of White Ink
Color CMYK /W+CMYK /CMYK+V/W+CMYK+V
Printing Resolution   Maximum 2400 dpi
Speed   720x900dpi (Finish Printing an A2 sheet in 5 mins)
Ink Curing Method   Dual UV LED Lights
Power   3000W
Interface   Gigabit Ethernet
Power Supply   AC 220V ± 5%, 16A 50HZ ±1
Dimensions(with stand)   2258mm(W)*1360(D)mm*1250mm(H)
Weight(with stand)   300kg
Environment Power on Temperature: 59℉to 90℉[15℃to 32℃] / Humidity: 35 to 80% (no condensation)
Power off Temperature: 41℉to 104℉[5℃to 40℃] / Humidity: 20 to 80% (no condensation)

Technical Specifications

UV DTF Printing Working Process

 Design Pattern
Use photoshop, illustrator or other software to design your pattern.


 Print Your Design On A Film
Adjust the printer parameters in the RIP software and use our UV DTF printer and ink to print your pattern on A film.


 Lamination
Laminate A film with B film

 Cut & Transfer Film On Products
Cut the image and stick on substrates, repeat pressing the pattern and then slowly peel the film and finish.

Applications of
UV DTF Printer
Print magic UV ink on magic film. Get ready to design and make your “image” without the traditional molding process, and no more minimum order quantity for your customer. Magic film can be applied easily on non-flat surface for printing image transfer,and works well on various materials,such as plastic,glass,metal,ceramics,leather,wood,and other soft or hard materials.
 Plastic                              Glass
 Ceramics                          Metal
 Leather                            Glass stickers
 Wood                               Packibg box
 and other soft or hard materials.......

Additional Value
01
Year Warranty
Within 1 year from the date of purchase, if the machine has non-man-made damage, you can enjoy free warranty service.
02

Online Technical Support
The expert team will serve you online and solve any problems you encounter for free.
03
Inkjet Printer Starter Kit
Starter kit pack including complete set of test inks, commonly used replacement parts,and the user's guide, installation Video Instructions.
04
Dealer’s Team Training
Regularly provide our dealers , technical training of new models, application solutions training, sales guidance training.
