OR-6042A--UV faltbed printer

The charming OR-6042AUV multi-functional flatbed printer can be used for not only sheet fed but also objects with non-flat surfaces, such as glass bottles, water cups, personalized mobile phone cases, gifts, promotional souvenirs, etc.Suitable for printing on: flat or cylindrical objects such as mobile phone case, metal, acrylic, plastic, PVC, glass, ceramics, wood, leather, etc
ORIC UV DTF MULTIFUNCTION FLATBED PRINTER
OR-6042A
Special for UV DTF Flatbed Printing,  Most advanced and latest printing technology

Parameter

Print Head: EPSON i1600-U1
Max Print Size: 600mm*420mm
Media Thickness : ≤1800mm
Finish Printing an A2 sheet : 10mins
Ink Type: UV Curing Ink

Feature

UV DTF Printing - The biggest advantage of this new technology is that after printing, it can be directly attached to the substrate to be transferred without other processing. UV DTF printing is especially suitable for transferring UV ink to special shapes and materials that are not suitable for direct printing by UV ink.
Download
New Feature of UV DTF Flatbed Printer
We have an excellent technical team, which can be designed according to customers requirements.
  • 01
    4 Colors + White & Varnish Are More Expressive
    Equipped with 6 ink tanks, 4 colors of ink can be installed. It can finish exquisite shading with high precision. In addition, using white ink and clear varnish, it has rich expressive power and fulfills various needs.
  • 02

    Print Varnish And 3D Relief Effects

    ​​​​​​​
    The heads of white color varnish ink jet at the same time, which can produce D relief and multi-layer transparent bump effect, including amazing varnish glossy effect and matte finish.
  • 03
    High-Performance Inks For A Variety Of Applications
    It is an eco-friendly UV ink with excellent color development and color reproducibility. It is cured by ultraviolet radiation. In addition to bright colors and style, it also has strong adhesion.
UV DTF Printing Working Process

 Design Pattern
Use photoshop, illustrator or other software to design your pattern.


 Print Your Design On A Film
Adjust the printer parameters in the RIP software and use our UV DTF printer and ink to print your pattern on A film.


 Lamination
Laminate A film with B film

 Cut & Transfer Film On Products
Cut the image and stick on substrates, repeat pressing the pattern and then slowly peel the film and finish.

Epson i1600-U1 Print Head


PrecisionCore Technology a. MEMS manufacturing and thin film piezo element can
realize  high precision and high density (600 npi/2 rows of nozzles). Contributes to
compact, high speed, high quality, and high image quality. b. Precision made of Epson
unique MEMS  nozzles and an ink flow path ensure the perfectly round ink droplets are
placed accurately  and consistently.

Epson i1600-U1 UV is a cost-effective 1.33inch-wide MEMs head series providing high productivity and high image quality with 600dpi high-density resolution. This printhead
is suitable for UV inks. It is unlocked.

dtg喷头2
Model I1600-U1
Compatible ink UV Ink
Dimensions(WidthxDepthx Height) 69.1mm x 59.4mm x 35.6mm
Weight(g) 60
Nozzle Numbers 1600
Length Between Nozzles(inch) 1/300
Nozzle Row 4 rows
Max color/head 4 colors
Resolution 300dpi/row, 600dpi/2row
Effective Printing Width(mm) 33.8
Droplet
ejection
performance(kHz)		 Binary 5 pl（43.2kHz）
3 levels
grey scale		 6,12.5 pl（21.6kHz）
4 levels
 grey scale		 3.8,6.2,9.3 pl（21.6kHz）
Viscosity range(mPa.s) 5-7 mPa･s

  •
  • Technical Specifications
  •
OR-6042A Multifunctional UV Flatbed Printer
Printing Technology   Double I1600-U1 Print Heads
Print Head   Piezoelectric Inkjet
Printing Width   600*420(mm)
Acceptable Media Width ≤600(mm)
Thickness ≤1800(mm)
Ink Cartridges Capacity Color Siphon + Regular Mixing of White Ink
Color W+CMYK+Varnish
Printing Resolution   Maximum 2400 dpi
Speed   720x900dpi （Finish Printing an A2 sheet in 10 mins）
Ink Curing Method   Dual UV LED Lights
Power   1300W
Interface   Gigabit Ethernet
Power Supply   AC 220V ± 5%, 16A 50HZ ±1
Dimensions(with stand)   61.88(W)x37.8(D)x36.4(H) in.
  ( 1572(W)x960(D)x925(H) mm )
Weight(with stand)   441 lb. (200 kg)
Environment Power on
Power off

Safety structure design

The overall printer cover can improve the operation safety, reduce the adhesion of dust in the printing process and ensure the printing quality.

Smart operation

High quality output, simple and efficient operation OR-6042UVA multifunctional flatbed contains many advanced functions to complete high-quality printing jobs with simple operations.

Suction platform

High precision vacuum flatbed made of aluminum alloy with a turbofan installed below can fix the media firmly.

Automatic height measurement

Up to 1800mm media thickness. The beam can rise to 180mm to print customized products.

Applications Of Flatbed UV Printer

  • PVC Card

    PVC Card
  • Canvas

    Canvas
  • Wood

    Wood
  • Metal

    Metal
  • Ceramics

    Ceramics
  • Glass

    Glass
  • Stainless steel

    Stainless steel
  • PVC Board

    PVC Board
  • Leather

    Leather
  • Acrylic crystal

    Acrylic crystal
  • Soft silicone

    Soft silicone
  • PET film

    PET film
Applications of
UV DTF Printer
Print magic UV ink on magic film. Get ready to design and make your “image” without the traditional molding process, and no more minimum order quantity for your customer. Magic film can be applied easily on non-flat surface for printing image transfer,and works well on various materials,such as plastic,glass,metal,ceramics,leather,wood,and other soft or hard materials.
 Plastic                              Glass
 Ceramics                          Metal
 Leather                            Glass stickers
 Wood                               Packibg box
 and other soft or hard materials.......
Additional Value
01
Year Warranty
Within 1 year from the date of purchase, if the machine has non-man-made damage, you can enjoy free warranty service.
02

Online Technical Support
The expert team will serve you online and solve any problems you encounter for free.
03
Inkjet Printer Starter Kit
Starter kit pack including complete set of test inks, commonly used replacement parts，and the user's guide, installation Video Instructions.
04
Dealer’s Team Training
Regularly provide our dealers , technical training of new models, application solutions training, sales guidance training.
